API Mock Stubbing Guide

This guide explains how to use mock stubs when calling APIs to simulate different responses without hitting real backend services.

Mock stubbing is available in non-production environments only (dev, agile, staging).

Quick Start

Enable mock responses by adding these headers to your API request:

X-Mock-Response: true
X-Mock-Path: /orders
X-Mock-Scenario: success

Required Headers

X-Mock-Response

• Required: Yes (to enable mocking)
• Value: true
• Description: Activates the mock stubbing middleware

X-Mock-Path

• Required: Yes
• Value: The API path pattern (e.g., /orders, /orders/{id}, /users/{id}/profile)
• Description: Specifies which stub file to use. Use {id} as a placeholder for dynamic path segments

X-Mock-Scenario

• Required: No
• Default: success
• Value: The scenario name (e.g., success, not-found, error, timeout)
• Description: Determines which stub variant to use for testing different cases

Path Patterns

Static Paths

For endpoints without dynamic parameters:

X-Mock-Path: /orders
X-Mock-Path: /users/settings

Dynamic Paths

Use {id} as a placeholder for IDs or dynamic segments:

X-Mock-Path: /orders/{id}
X-Mock-Path: /users/{id}/profile
X-Mock-Path: /companies/{id}/employees/{id}

Note: Leading and trailing slashes are optional - all these work the same:

• orders/{id}
• /orders/{id}
• /orders/{id}/

Common Scenarios

Success Response

curl -X GET https://api.example.com/orders/123 \
  -H "X-Mock-Response: true" \
  -H "X-Mock-Path: /orders/{id}" \
  -H "X-Mock-Scenario: success"

Not Found (404)

curl -X GET https://api.example.com/orders/999 \
  -H "X-Mock-Response: true" \
  -H "X-Mock-Path: /orders/{id}" \
  -H "X-Mock-Scenario: not-found"

Server Error (500)

curl -X POST https://api.example.com/orders \
  -H "X-Mock-Response: true" \
  -H "X-Mock-Path: /orders" \
  -H "X-Mock-Scenario: server-error" \
  -H "Content-Type: application/json" \
  -d '{"product": "widget"}'

Validation Error

curl -X POST https://api.example.com/orders \
  -H "X-Mock-Response: true" \
  -H "X-Mock-Path: /orders" \
  -H "X-Mock-Scenario: validation-error" \
  -H "Content-Type: application/json" \
  -d '{"product": ""}'

Dynamic Templating

Stub responses can include values pulled from your request using {{ ... }} syntax, so the response echoes back data you sent.

Available Template Variables

Complete Examples

Example 1: Get Order by ID

Request:

curl -X GET https://api.example.com/orders/12345 \
  -H "X-Mock-Response: true" \
  -H "X-Mock-Path: /orders/{id}" \
  -H "X-Mock-Scenario: success"

Response:

{
  "id": "12345",
  "status": "shipped",
  "items": [
    {
      "product": "Widget",
      "quantity": 2,
      "price": 29.99
    }
  ],
  "total": 59.98
}

Example 2: Create Order

Request:

curl -X POST https://api.example.com/orders \
  -H "X-Mock-Response: true" \
  -H "X-Mock-Path: /orders" \
  -H "X-Mock-Scenario: success" \
  -H "Content-Type: application/json" \
  -d '{
    "product": "Gadget",
    "quantity": 3,
    "userId": "user-456"
  }'

Response: (HTTP 201)

{
  "id": "new-order-789",
  "product": "Gadget",
  "quantity": "3",
  "userId": "user-456",
  "status": "pending",
  "createdAt": "2026-03-19T10:30:00Z"
}

Example 3: Not Found Error

Request:

curl -X GET https://api.example.com/orders/99999 \
  -H "X-Mock-Response: true" \
  -H "X-Mock-Path: /orders/{id}" \
  -H "X-Mock-Scenario: not-found"

Response: (HTTP 404)

{
  "error": "Order not found",
  "orderId": "99999",
  "message": "No order exists with ID 99999"
}

Testing Different Scenarios

Common scenarios you can test:

Error Responses

When Mock Headers Are Missing

Missing X-Mock-Path:

{
  "error": "X-Mock-Path header is required",
  "example": "X-Mock-Path: /orders"
}

Status: 400 Bad Request

When Stub Not Found

{
  "error": "Failed to fetch mock stub",
  "reason": "HTTP 404"
}

Status: 502 Bad Gateway

Tips & Best Practices

1. Use descriptive scenario names - Make it clear what behavior you're testing
2. Leverage {id} placeholders - Reuse stubs for any ID value
3. Test error cases - Don't just test happy paths
4. Consistent stub structure - Use the same patterns across your team
5. Document custom scenarios - Share available scenarios with your team

Troubleshooting

Q: Mock headers aren't working

• Ensure X-Mock-Response: true is set (case-sensitive headers)
• Verify X-Mock-Path is provided
• Check that mock stubbing is enabled for this API and environment

Q: Getting 404 errors

• Verify a stub exists for this path, method, and scenario
• Check with your API team whether the scenario name is correct

Q: Template variables showing as empty

• Ensure you're using the correct template syntax: {{request.path.id}}
• Check that path parameters match the pattern (e.g., {id} in path)
• Verify request body is valid JSON for body templates

Q: How do I find available scenarios?

• Check with your API team for the scenarios available for that endpoint
• Common scenarios are usually: success, not-found, error
• To request a new scenario, ask your API team to add it
